Eglobal intel Mini PC 10th Intel core i9 10980HK powerful 3 display 4K NMVe Gaming computer dual la
You can buy sample unit to test directly if PayPal is available for you.
The link is for the following Specification: Barebone System
- No RAM
- No Storage
- AC WIFI with Dual Antennas
- Windows 10/Linux
- Including DHL/FedEx/UPS/EMS/Postage shipping
The Package includes:
1 * Mini PC Device
1 * EU/AM/BR/AU standard Power Adapter
1 * Set of SATA power and data cables(for 2.5" hard drive installation)
1 * Plastic Stand Holder
2 * WiFi Antennas
1 * HDMI Cable
Product Highlight
- Onboard Intel Coffee Lake 10th/9th/8th generation powerful processor for online games.
- 2xSODIMM DDR4 memory slot up to 64GB more powerful performance improve work efficiency and give you a smooth experience.
- Support HDMI, DP and Type-C for triple 4K display output synchronously and asynchronously.
- Support 2*M.2 2280 NVME/PCIE3.0x4 SSD+1*2.5'' SATA HDD/SSD(7mm thickness).
- Support 2*Gigabit RJ45 Lans+M.2 2230 2.4G/5G Dual band AC(AX) WiFi/Bluetooth.
- Brushed Aluminum Alloy Black color shell, Exquisite production craft on outside design.
- Onboard a power copper fan for heat dissipation can keep the computer steady working long time.
- Support VT-x, PXE, RTC, Wake on LAN, Auto power on.
|
Basic Information: |
|
CPU |
10th Gen 16nm Intel core i9 10980HK 8cores 16threads 2.4GHz UP to 5.30GHz Intel UHD Graphics 350MHz-1.25GHz |
|
CPU Installation Method |
FCBGA1440 |
|
TDP |
45W |
|
Level 3 Cache |
16MB |
|
Motherboard |
144.2 x 141.0 mm |
|
BIOS |
American Megatrends Inc. |
|
Code Name |
Intel Coffee Lake |
|
Chipset |
HM370 Chipset |
|
Memory |
2 x SO-DIMM Slot, up to 64GB DDR4
Dual Channel, DDR4-2800MHz, DDR4-2666MHz, DDR4-2400MHz, DDR4-2133MHz |
|
OS |
Windows/Linux |
|
Audio |
Intel High Definition Audio Controller Intel Display Audio
Intel High Definition Audio Controller |
|
Network |
2 x Realtek RTL8168/8111/8112 Gigabit Ethernet Controller
10/100Mbps/1000Mbps BaseT LAN |
|
Video |
Intel® UHD Graphics 630 |
|
Input/output port |
|
Switch |
1 x Power On/Off Switch |
|
Power |
1 x 19V DC In |
|
LED |
1 x LED |
|
USB |
4 x USB3.0, 2X USB2.0 |
|
Type-C |
1 x Type-C3.1 |
|
Display |
1 x DP, 1 x HDMI |
|
LAN |
2 x RJ45 Giga LAN |
|
Audio |
1 x Audio(MIC&SPK) |
|
Storage |
|
|
M.2 |
1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(Only NVME PCIe3.0x4), support 6Gb/s
1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(NVME/SATA), support 6Gb/s |
|
SATA |
1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s |
|
Wi-Fi |
|
|
Module |
1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G or 5G Wi-Fi B/G/N/AC or Bluetooth) |
|
Antenna |
2 x inner RF cables and 2 x external antennas |
|
Power and Working Environment |
|
Input |
DC100-240V AC/50-60Hz |
|
Output |
DC +12V~+19V, recommend 19V/5A |
|
Operating Temperature |
0/70 Centigrade |
|
Storage Temperature |
-20/+80 Centigrade |
|
Relative Humidity |
0%~90% (non-condensing) |
|
Product Dimension & Details |
|
Size |
149.5*145.5*66.1mm |
|
Weight |
Net 1.9kg, Gross 2.5KG |
|
Shell |
Dark gray color aluminum alloy |
|
Cooling Mode |
Copper Cooling Fan |
|
Functions |
RTC, PXE |
|
Package Content |
|
|
Standard |
1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag |
|
Optional |
Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xVESA Mount |
|
|
|
