Eglobal New arrival Best Mini PC intel core i9 10980Hk 8 cores 2.4GHz up to 5.3GHz gaming computer

1 * HDMI Cable

Product Highlight:

- 2xSODIMM DDR4 memory slot up to 64GB.

- Dual Intel RJ45 Gigabit LAN ports.

- Support M.2 NGFF NVME/SATA 22*80 SSD+M.2 NGFF NVME/PCIE*4 22*80 SSD+2.5'' SATA HDD.

- Support DP1.2 out(support 4k@60Hz) and HDMI2.0 out(support 4K@60Hz) dual display .

- Brushed Aluminum Alloy Black color shell, Exquisite production crati on outside design.

- Onboard a copper fan for heat dissipation can keep the computer steady working long time.

- One Kensington Lock hole keep the computer more safe in school, offiffiffice, hotel, etc.

Basic Information
CPU	10th Gen 14nm CPU Comet Lake Intel Core i9-10980HK 8 cores 16 threads 2.4GHz up to 5.3GHz 16MB cache TDP 45W Intel UHD Graphics.
CPU install Method	BGA1440
TDP	45W
Level 2 Cache	Depend on CPU
Motherboard	136 x 126mm customized size
Code Name	Intel Coffee Lake
Chipset	Intel 300 series PCH
Memory	2 x SO-DIMM Slot, up to 64GB DDR4 Dual Channel, DDR4-2800MHz, DDR4-2666MHz, DDR4-2400MHz, DDR4-2133MHz ECC Memory Support: YES
OS	Windows 10
Audio	Azalia Codec support 2.1 channel output High Definition Audio Controller
Network	1)10/100/1000Mbps Ethernet 2) Intel® Ethernet Connection I219-V 3) Intel® Ethernet Connection I211-AT
Video	Intel® UHD Graphics 630
Input/output port
Switch	1 x Power On/Off Switch
Power	1 x 19V DC In
LED	1 x LED
USB	4 x USB3.0, 2 x USB2.0
Type-C	1 x Type-C USB3.1
Display	1 x DP1.2 out(support 4k@60Hz), 1 x HDMI2.0 out(support 4K@60Hz)
LAN	2 x RJ45 Intel Giga LAN
Audio	1 x Audio(MIC&SPK)
Others	1 x Kensington Lock hole
Storage
MSATA	1 x M.2 slot for M.2 NGFF 2280(Key M), up to 2TB(Only NVME PCIe3.0x4), support 6Gb/s 1 x M.2 slot for M.2 NGFF 2280(Key M), up to 2TB(NVME/SATA), support 6Gb/s
SATA	1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s
Wi-Fi
Module	1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G or 5G Wi-Fi B/G/N/AC or Bluetooth)
Antenna	2 x inner RF cables and 2 x external antennas
Power and Working Environment
Input	DC100-240V AC/50-60Hz
Output	DC +12V~+19V, recommend 19V 90W
Operating Temperature	0/70 Centigrade
Storage Temperature	-20/+80 Centigrade
Relative Humidity	0%~90% (non-condensing)
Product Dimension & Details
Size	13414464mm
Weight	Net 1.05kg, Gross 3.0kg
Shell	Brushed Black color aluminum alloy
Cooling Mode	Cooling Fan
Functions	1) Intel® Optane™ Memory Supported: Yes 2) Intel® Virtualization Technology (VT-x): Yes 3) Wake on Lan : Yes 4) Wake on AC : Yes 5) PXE Boot: Yes.
Package Content
Standard	1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag, 1xVESA mount
Optional	Wi-Fi antennas, 1xHDMI cable, 1xUser Manua
