| Latest CPU processor Mini PC Eglobal Fanless intel core i7 10510U Mini gaming computer hot selling Product highlight:
- Latest powerful processor Intel 10th Gen and 2xSODIMM DDR4 memory slot up to 64GB stronger performance and give you a smooth experience.
- Full Aluminum Alloy Black color shell, Exquisite production craft on outside design.
- Fanless system without cooling fan, no any noise, work as long as 24 hours.
- Low consumption TDP only 15W, save much energy and eco-friendly.
- Can stand up by free bracket or can be mounted back of monitor or wall.
- Can install M.2 SSD+MSATA SSD+2.5” SATA HDD together.
- Support DP + HDMI dual display output synchronously.
You can buy sample unit to test directly if PayPal is available for you.
The link is for the following Specification: Barebone System
- No RAM
- No Storage
- AC WIFI with Dual Antennas
-Windows 10/Linux
- Including DHL/FedEx/UPS/EMS/Postage shipping
The Package includes:
1 * Mini PC Device
1 * EU/AM/BR/AU standard Power Adapter
1 * Set of SATA power and data cables(for 2.5" hard drive installation)
1 * Plastic Stand Holder
2 * WiFi Antennas
1 * HDMI Cable
1 * VESA mount(optional)
|
Basic Information: |
|
CPU |
Onboard Intel Comet Lake Intel Core i7 10510U 1.8GHz up to 4.90GHz Quad Cores 8 Threads |
|
TDP |
15W |
|
Motherboard |
170 x 170mm customized size |
|
BOIS |
AMI BIOS, ACPI supported |
|
Chipset |
Intel Comet Lake |
|
Memory |
2 x SO-DIMM DDR4 Slot
Support 4GB/8GB/16GB/32GB/64GB
DDR4-2666, LPDDR3-2133 |
|
PXE |
YES |
|
OS |
Windows 10/Linux |
|
Audio |
ALC897 chip, 7.1 channel sound
Intel Lynx Point-LP HDA |
|
Network |
Onboard Realtek RTL8168/8111/8112 PCI-E Gigabit Ethernet NIC
Onboard RTL8111DL10/100Mbps/1000Mbps BaseT LAN |
|
Video |
Intel® UHD Graphics |
|
Input/output port |
|
Switch |
1 x Power On/Off Switch |
|
Power |
1 x 12V DC In |
|
LED |
1 x LED |
|
USB |
4 x USB2.0, 4 x USB3.0 |
|
Display |
1 x DP, 1 x HDMI |
|
LAN |
1 x RJ45 Intel Giga LAN |
|
Audio |
1 x MIC, 1 x SPK |
|
Storage |
|
|
MSATA |
1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s
1 x M.2 slot for M.2 SSD, support 6Gb/s |
|
SATA |
2 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s |
|
Wi-Fi |
|
|
Module |
1 x mini-PCIE port for Wi-Fi module |
|
Antenna |
2 x inner RF cables and 2 x external antennas |
|
Power and Working Environment |
|
Input |
DC100-240V AC/50-60Hz |
|
Output |
DC +12V~+19V, recommend 12V/5A |
|
Operating Temperature |
0/70 Centigrade |
|
Storage Temperature |
-20/+85 Centigrade |
|
Relative Humidity |
0%~90% (non-condensing) |
|
Product Dimension & Details |
|
Size |
210*170*45mm |
|
Weight |
Net 1.8kg, Gross 2.7kg |
|
Shell |
Black color aluminum alloy |
|
Cooling Mode |
Fanless |
|
Functions |
Calls on function automatically, RTC, AWAL |
|
Package Content |
|
|
Standard |
1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag, 1xBracket |
|
Optional |
Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xVESA mount |
|
|
|
