Computer Dimension:

234*150*43mm

GW: 2.5KG

Key Features & Benefits:

• Fanless System, CPU without fan, no noise
• Black Full Brushed-aluminum Case
• Support 3D games and HDMI 1080P
• Support calls on function automatically
• WiFi with Dual Antenna
• Can install 1pc HDD and 1pc SSD together
• Dual RJ45 Lan, 4 * RS232 COM port
• CE, FCC, ROHS Certification


General
Processor	Intel Core i5 3317U1.7GHz Max 2.6GHz Dual Core 4 thread
Operating System	Windows 7/Windows 8/Windows 10/ Linux
Storage	SSD: 8GB/16GB/32GB/64GB/128GB/256GB/512GB HDD: 160GB/320GB/500GB/750GB/1TB
Memory	2GB/4GB/8GB DDR3
Model	Intel NM77 Express High Speed Chipset
Processor details
CPU	Intel Core i5 3317U
Speed	1.7GHz(100MHz x 17.0)
Processor Number	2 core/ 4 threads
Max Turbo Frequency	2.6GHz
Core code	Ivy Bridge
Technique	22nm
L1 data cache	2 * 32 KB
L2 code cache	2 * 32 KB
L3 cache	3 MB, CPU Integrated
Characteristic	MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AVX
BIOS	AMI BIOS, ACPI supported, support call on fanction automatically
Function	Hyper-Threading, Virtualization technology, 64 bit computing
Graphic Cards	Intel HD Graphics 4000 Fundamental Frequency 350MHz Max Frequencty 1050MHz
Audio Cards	ALC662 sound chip, 6-channel
Network card	RTL8111DL PCI-E Gigabit Ethernet NIC
Ethernet	10/100/1000 BaseT LAN
WIFI	With dual antennas, 802.11.b/g/n(300M or 300M WIFI&Bluetooth)
I/0 Port
Display port	1* VGA + 1 * HDMI
COM Port	4 * RS232 COM
USB port	4* USB 3.0, 4 * USB2.0
SATA port	1 * MSATA3.0, 6Gb/s; 1 * SATA3.0 , 6Gb/s
MINI PCIE	1 * MSATA SSD, 1 * WiFi module
Ethernet port	2 * RJ45 10/100/1000 Mbps Adaptive
Power input port	1 inner diameter 2.5mm,external diameter 5.5mm
Audio port	Standard 3.5 Audio input and output
Power and Working Environment
Input	DC100-240V AC/50-60Hz
Output	DC 12V/6A
Type	External power adapter mode
Consumption	17W
Noise	Fanless System
Temperature	0-70 Centigrade
Humidity	10%-90%
