Eglobal new arrival desktops intel core i9 9880H powerful mini gaming pc dual lan dual display
- 2xSODIMM DDR4 memory slot up to 64GB.
- Dual Intel RJ45 Gigabit LAN ports.
- Support M.2 NGFF NVME/SATA 22*80 SSD+M.2 NGFF NVME/PCIE*4 22*80 SSD+2.5'' SATA HDD.
- Support DP1.2 out(support 4k@60Hz) and HDMI2.0 out(support 4K@60Hz) dual display .
- Brushed Aluminum Alloy Black color shell, Exquisite production craft on outside design.
- Onboard a copper fan for heat dissipation can keep the computer steady working long time.
- One Kensington Lock hole keep the computer more safe in school, office, hotel, etc.
You can buy sample unit to test directly if PayPal is available for you.
The link is for the following Specification: Barebone System
- No RAM
- No Storage
- AC WIFI with Dual Antennas
-Windows 10/Linux
- Including DHL/FedEx/UPS/EMS/Postage shipping
The Package includes:
1 * Mini PC Device
1 * EU/AM/BR/AU standard Power Adapter
1 * Set of SATA power and data cables(for 2.5" hard drive installation)
1 * Plastic Stand Holder
2 * WiFi Antennas
1 * HDMI Cable
1 * VESA mount(optional)
|
Basic Information: |
|
CPU |
Intel Core i9-9880H / Intel Core i9-8950HK |
|
CPU install Method |
BGA1440 |
|
TDP |
45W |
|
Level 2 Cache |
Depend on CPU |
|
Motherboard |
136 x 126mm customized size |
|
Code Name |
Intel Coffee Lake |
|
Chipset |
Intel 300 series PCH |
|
Memory |
2 x SO-DIMM Slot, up to 64GB DDR4
Dual Channel, DDR4-2800MHz, DDR4-2666MHz, DDR4-2400MHz, DDR4-2133MHz
ECC Memory Support: YES |
|
OS |
Windows 10 |
|
Audio |
Azalia Codec support 2.1 channel output
High Definition Audio Controller |
|
Network |
1)10/100/1000Mbps Ethernet
2) Intel® Ethernet Connection I219-V
3) Intel® Ethernet Connection I211-AT |
|
Video |
Intel® UHD Graphics 630 |
|
Input/output port |
|
Switch |
1 x Power On/Off Switch |
|
Power |
1 x 19V DC In |
|
LED |
1 x LED |
|
USB |
4 x USB3.0, 2X USB2.0 |
|
Type-C |
1 x Type-C USB3.1 |
|
Display |
1 x DP1.2 out(support 4k@60Hz), 1 x HDMI2.0 out(support 4K@60Hz) |
|
LAN |
2 x RJ45 Intel Giga LAN |
|
Audio |
1 x Audio(MIC&SPK) |
|
Others |
1 x Kensington Lock hole |
|
Storage |
|
|
MSATA |
1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(Only NVME PCIe3.0x4), support 6Gb/s
1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(NVME/SATA), support 6Gb/s |
|
SATA |
1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s |
|
Wi-Fi |
|
|
Module |
1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G or 5G Wi-Fi B/G/N/AC or Bluetooth) |
|
Antenna |
2 x inner RF cables and 2 x external antennas |
|
Power and Working Environment |
|
Input |
DC100-240V AC/50-60Hz |
|
Output |
DC +12V~+19V, recommend 19V 90W |
|
Operating Temperature |
0/70 Centigrade |
|
Storage Temperature |
-20/+80 Centigrade |
|
Relative Humidity |
0%~90% (non-condensing) |
|
Product Dimension & Details |
|
Size |
134*144*64mm |
|
Weight |
Net 1.05kg, Gross 3.0kg |
|
Shell |
Brushed Black color aluminum alloy |
|
Cooling Mode |
Cooling Fan |
|
Functions |
1) Intel® Optane™ Memory Supported: Yes
2) Intel® Virtualization Technology (VT-x): Yes
3) Wake on Lan : Yes
4) Wake on AC : Yes
5) PXE Boot: Yes. |
|
Package Content |
|
|
Standard |
1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag, 1xVESA mount |
|
Optional |
Wi-Fi antennas, 1xHDMI cable, 1xUser Manual |
